Smart BGA Rework Equipment/R7830A

Maker: Seamark ZM

Made in: China

Dimensions: L810mm×W1100mm×H950mm

Power Supply: AC380V±10% 50/60Hz

IR Temp. Zone Size: 500×380mm

Control System: Panasonic PLC+Temp control module

Weight: 151KG

Liên hệ

R7830A is optical Alignment Automatic Rework Equipment

Excellent Performance Features

  • Multilingual menu interface.
  • Automatic feeding device.
  • X/Y axis can be controlled by joystick, operation is quick and convernient.
  • Imported high-definition CCD (2M pixel) optical alignment system.
  • High-precision temperature control sensing system.

X/Y/Z Axis Automatic Displacement

The top temperature zone is controlled by the joystick control servo system, which can automatically move and align at fast/slow speed by X/Y/Z Axis.

Vacuum Adsorption and Nitrogen Protection

The top heating head has a built-in vacuum suction nozzle for chip adsorption, electrically controlled 360-degree rotation alignment, with negative pressure monitoring and presure protection divice. The bottom temperature zone adopts a large-area heating wire layout, moves symmetrically with the top temperature zone, and can be connected with nitrogen to prevent PCBA from yellowing.
